Capacity Range : 60~600 l/min

          Speed Range : 50~500 rpm

          Discharge Pressure : 0~15 kg/cm2

          Temperature : -20~350 c

          Motor Power  : 3.75~22 Kw

          Viscosity : 1~150,000 Cps

          Material : SCS13, SCS14, SCM4, ALLOY-20,

                                                                     HASTELLOY-C

                                                                          Pump Feature : Jacket, Relief Value Type

¡¡

¡¡

¡¡

¡¡

¡¡
